The product has the function of beacon, compatible with ibecon, but also has temperature, humidity, light, ultraviolet and other sensors. It can broadcast the collected temperature, humidity and light to mobile phone or gateway through beacon broadcast.
|
Product information
|
| Bluetooth standard |
V5.0 BLE
|
| Size |
35.5mm*18mm(1.39*0.7 in)
|
| Receiving sensitivity |
< -88dBm at < 0.1% BER
|
| Frequency range |
ISM band 2.400～2.483GHz
|
| Transmission distance |
15M
|
| Operating temperature: |
-40゜C ~ +85゜C
|
| Storage temperature: |
-55゜C ~ 125゜C
|
| Temperature test range |
-40゜C ~ +85゜C
|
| Measurement accuracy |
15゜C ~ +40゜C, deviation ±0.5゜C.
-40゜C ~ +85゜C, deviation ±1゜C.
|
Relative humidity
measurement range |
0 ~ 100%
|
| Humidity accuracy |
20% ~ 80% RH, deviation ±4.5% RH.
|
UV index
measurement range |
0 ~ 15.
|
Light intensity
measurement range |
0 ~ 83886.08 lx.
|
|
|
|
|
|
The product has the function of beacon and is compatible with ibecon. It also has a temperature and humidity sensor, which can broadcast the collected temperature and humidity to the mobile phone or gateway through beacon.
|
Product information
|
| Bluetooth version |
V5.0BLE
|
| Receiving sensitivity |
< -93dBm at < 0.1% BER
|
| Frequency range |
ISM band 2.400～2.483GHz
|
| Transmission distance |
10 ~ 40M (built in antenna up to 40m)
|
| Temperature test range |
-40゜C ~ +85゜C
|
| Measurement accuracy |
-10゜C ~ +85゜C, deviation ±0.4゜C.
-40゜C ~ -10゜C, deviation ±0.9゜C.
|
Relative humidity
measurement range |
0 ~ 100%
|
| Humidity accuracy |
0 ~ 80% RH, deviation ±3% RH.
80% ~ 100% RH, deviation ±4.5%
|
|
|
|
|
|
The product can send the collected temperature and humidity data to the mobile phone or gateway through beacon broadcast.
The product can send the collected temperature and humidity data to the mobile phone or gateway through beacon broadcast.
|
Product information
|
| Size |
40mm*14mm
|
| Bluetooth version |
V5.0 BLE
|
| Receiving sensitivity |
<－96dBm at < 0.1% BER
|
| Frequency range |
ISM band 2.400～2.483GHz
|
| Transmission distance |
Built in antenna up to 30 meters
|
| Battery |
CR2450
|
| Operating temperature: |
-40゜C ~ 85゜C
|
| Storage temperature: |
-55゜C ~ 125゜C
|
| Temperature test range |
-40゜C ~ +85゜C
|
| Measurement accuracy |
-10゜C ~ +85゜C, deviation ±0.4゜C.
-40゜C ~ -10゜C, deviation ±0.9゜C.
|
Relative humidity
measurement range |
0 ~ 100%
|
| Humidity accuracy |
0 ~ 80% RH, deviation ±3% RH.
80% ~ 100%, deviation ±4.5%.
|
|
It can store up to 100W temperature and time data
|
When the mobile phone reads the stored data,
the speed is about 1500 pieces / s
|
|
|
|
|
|
The nine-axis accelerometer product integrates accelerometer, gyroscope, magnetometer and other sensor chips.
|
Product information
|
| Bluetooth version |
V5.0BLE
|
| Size |
49.3 * 37.6 * 22.2mm
|
| Operating frequency |
ISM band 2.402 ~ 2.480GHz (Step 2MHz) |
| Transmission distance |
25M
|
| Operating temperature |
-20°C ~ +70°C
|
| Storage temperature |
-55°C ~ +125°C
|
| Power supply mode |
built-in lithium battery
|
| Acceleration acquisition range |
lithium battery 3.7V 400mAh
|
| Working power supply |
-2g~+2g /-4g~+4g/-8g~+8g/ -16g~+16g
|
| AGyroscope angular velocity acquisition range |
250dps, 500dps, 1000dps, 2000dps
|
| Magnetometer acquisition range |
4Guass, 8Guass, 12Guass, 16Guass
|
|
|
|
|
|
The 6-axis accelerometer product integrates accelerometer, gyroscope and other sensor chips.
|
Product information
|
| Bluetooth version |
V5.0BLE
|
| Size |
4mm*10.0mm(1.34*0.39in)
|
| Voltage |
2.7~3.3V
|
| Frequency range |
ISM band 2.402 ~ 2.480GHz
|
| Transmission distance |
10 ~ 30M
|
| Working temperature |
-40゜C ~ 85゜C
|
| Acceleration acquisition range |
-2g~+2g, -4g~+4g, -8g~+8g, -16g~+16g
|
Acquisition range
of angular velocity |
250dps, 500dps, 1000dps, 2000dps
|
| Measurement accuracy |
1%
|
Range of accelerometer
and gyroscope |
-32768 ~ +32767
|
|
|
|
|
|
